InstantKon SF70 Instruction Manual

InstantKon SF70 Instruction Manual
3 Ways to Sync Your Strobes to Your InstantKon SF70
  • Connecting the External Flash
  • SF70 includes a 2.5mm audio jack to trigger external flash units.
  • Make sure you’re using a 2.5mm Cable (Mono Jack Plug)
  • The flash will not work with shutter speeds faster than 1/125.
  • Turn off the TTL function of your flash.

2.5mm ── [PC sync / 3.5mm / 2.5mm] ── Flash

Download

2.5mm ── Hot shoe ── [PC sync / 3.5mm / 2.5mm] ── Flash

Remote trigger: 2.5mm ── Transmitter [3.5mm / 2.5mm] ─ ─ Receiver

 Getting started with your SF70

Opening and closing the camera:

The hinge locks the camera in its position. When the hinge is fastened, it will lock the camera in place. Watch out when opening and closing the camera.

Opening:-

  1. Open the camera by pressing the front cover lock.
  2. Straighten the cover braces to open it fully.
  3. Make sure the braces are straight. When the hinge is fastened, it will lock the camera in place.

Closing:-

  1. Set the focusing ring to Infinity position.
  2. Press the button next to the camera until the hinge detaches completely from the hole before folding the camera, or else it might break.
  3. Close the front cover. The lens will retract as the front cover closes.

Enjoy shooting with your SF70!
